Technical Specifications
General
| Orifice | 45mm |
|---|---|
| CV | 52.8 |
| Valve Type | 2 Way, Bi-Directional |
| Action | Direct Piston Actuation |
| De Energized State | Normally Open (NO) |
| Op Temp | Media: -5°F to 365°F (-20°C to 180°C) |
| Service | Liquid, Water, Air, Gas, Steam |
| Installation | Any Orientation |
| Brand | STC Valve |
| Manufacturer Part | 2KS-2-O |
| Size | 2″ |
Materials & Construction
| Body Material | 316 Stainless Steel / CF8M |
|---|
Performance
| Inlet Below Valve Seat Pressure at 180°C | 0 PSI to 90 PSI |
|---|---|
| Controlling Pressure Range | 65 PSI to 120 PSI |
Download Specification Sheet (PDF)
